DCP30DCP30 series controllable rectifier DC power supply

Model
DCP30
Frequency
45HZ-65HZ
Cooling method
Air cooling
Main circuit voltage
AC50-380V
Control voltage
AC160-240V
Optional specifications
100A，150A，200A，300A，400A，500A，600A，800A，1000A，1500A
Optional extension
/
13488970263 Inquiry Download
Main parameters

Specifications

100

150

200

300

400

500

600

800

1000

1500

Rated current

100A

150A

200A

300A

400A

500A

600A

800A

1000A

1500A

Dimensions (MM) (length, width, height)



335*165*214

420*245*238

435*265*255

435*265*255

570*395*245

675*479*292

770*479*291

Custom sizing

Power parameters

Main circuit: AC50-380V; Control board power supply: AC160-240V; Frequency: 45HZ-65HZ

Cooling method

Air cooling

Protection function

Protection functions such as phase loss, overcurrent, overheating, overload, load disconnection, frequency, etc

Port

0-5V/0-10V/0-20mA/4-20mA analog input, 3-channel switch input, 1-channel switch output; MODBUS-RTU

Extension module

/

Control mode

Constant voltage, constant current, open-loop control

Load type

Resistive, inductive, customizable according to specific loads

Accuracy

≤1%

Static Stability

≤0.2%

Usage environment

0.025%
